Baumer EIL580 Series Optical Incremental Encoder, 1024 ppr, HTL/Push Pull Signal, Solid Type, 10mm Shaft | EIL580-SC10.5BN.01024.A

Name: Baumer EIL580 Series Optical Incremental Encoder, 1024 ppr, HTL/Push Pull Signal, Solid Type, 10mm Shaft | EIL580-SC10.5BN.01024.A
SKU: 5073-028
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 13 pcs

Mfr. Part No: EIL580-SC10.5BN.01024.A

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 5073-028 Categories: Baumer, Motion Control Sensors

Description

Specifications

Attribute	Value
Brand	Baumer
Encoder Technology	Optical
Series	EIL580
Pulses Per Revolution	1024
Maximum Revolutions	12000rpm
Output Signal Type	HTL/Push Pull
Shaft Type	Solid
Shaft Diameter	10mm
Supply Voltage	8 → 30 V dc
IP Rating	IP65
Overall Width	58mm
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+85°C
Mounting Type	Clamping Flange
Connection Type	Flange connector M12
Switching Frequency	≤160 kHz, ≤300 kHz

Product Details

EIL580 – Solid shaft

EIL580 incremental encoders with solid shaft, with clamping or synchro flange.

Stainless steel solid shaft
Die-cast aluminium housing
Precise optical sensing
Axial, radial or tangential connection
High resistance to shock and vibrations
58 mm diameter

Baumer

Incremental rotary encoders.
