Baumer EIL580 Series Optical Incremental Encoder, 2048 ppr, HTL/Push Pull Signal, Solid Type, 10mm Shaft | EIL580-SC10.5FN.02048.A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: EIL580-SC10.5FN.02048.A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Encoder Technology | Optical |
| Pulses Per Revolution | 2048 |
| Series | EIL580 |
| Maximum Revolutions | 12000rpm |
| Output Signal Type | HTL/Push Pull |
| Shaft Type | Solid |
| Supply Voltage | 8 → 30 V dc |
| Shaft Diameter | 10mm |
| IP Rating | IP65 |
| Overall Width | 58mm |
| Minimum Operating Temperature | -40°C |
| Mounting Type | Clamping Flange |
| Maximum Operating Temperature | +85°C |
| Connection Type | Flange connector M23 |
| Switching Frequency | ≤160 kHz, ≤300 kHz |
Product Details
EIL580 – Solid shaft
EIL580 incremental encoders with solid shaft, with clamping or synchro flange.
Stainless steel solid shaft
Die-cast aluminium housing
Precise optical sensing
Axial, radial or tangential connection
High resistance to shock and vibrations
58 mm diameter
Die-cast aluminium housing
Precise optical sensing
Axial, radial or tangential connection
High resistance to shock and vibrations
58 mm diameter
Baumer
Incremental rotary encoders.
