Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Thread Size | M8 |
| Sensor Technology | Inductive |
| Detection Range | 5 mm |
| Body Style | Block |
| Digital Switching Output Type | PNP |
| Output Function | NO |
| Connection Type | M8 |
| Supply Voltage | 10 → 50 V dc |
| Length | 32mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Housing Material | Brass Nickel Plated |
| Width | 20mm |
| Maximum DC Voltage | 50V |
| Minimum Operating Temperature | -25°C |
| Depth | 10mm |
| Short Circuit Overload Protection | Yes |
| Standards Met | CE, cULus Listed, EAC |
| Switching Frequency | 1 kHz |
| Reverse Polarity Protection | Yes |
| Switching Current | 200 mA |
| Maximum Switching Frequency | 1kHz |
| Maximum Operating Temperature | +75°C |
| Shielding | Unshielded |
Product Details
Parallelepiped box sensor
PNP output with closure (N/O) and M8 connector.
IP67 nickel-plated brass shell.
Protected against reverse polarity and short circuits.
