Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Sensor Technology | Inductive |
| Body Style | Smooth Barrel |
| Detection Range | 3 mm |
| Output Function | NO |
| Digital Switching Output Type | PNP |
| Cable Length | 2m |
| Connection Type | Pre-Cabled |
| Supply Voltage | 6 → 36 V dc |
| Length | 40mm |
| IP Rating | IP67 |
| Mounting Type | Flush |
| Housing Material | Stainless Steel |
| Maximum DC Voltage | 36V |
| Diameter | 6.5 mm |
| Minimum Operating Temperature | -25°C |
| Switching Frequency | 2 kHz |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
| Shielding | Shielded |
| Maximum Switching Frequency | 2kHz |
| Switching Current | 100 mA |
| Maximum Operating Temperature | +75°C |
| Standards Met | CE, cULus Listed, EAC |
Product Details
Miniature Detectors Ø 6.5 mm
PNP output with closure (N/O) by cable or M8 3-point connector (available from the catalogue).
LED operation indication.
Protected against reverse polarity and short circuits.
