Baumer NE1218 Counter, 5 Digit LED, 15kHz, 10.5 → 70 V dc, 21 → 53 V ac | NE1218.0B5AX01
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: NE1218.0B5AX01
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Supply Voltage | 10.5 → 70 V dc, 21 → 53 V ac |
| Count Mode | Frequency, Pulse, Time |
| Display Type | LED |
| Function | Counter |
| Input Type | Namur, NPN, PNP, TTL |
| Connection Type | Plug-In |
| Number of Digits | 5 |
| Mounting Type | DIN Rail |
| Output / Interface | Relay |
| Count Direction | Bi-Directional |
| Digit Height | 14 mm |
| Maximum Count Frequency | 15kHz |
| Display Range | -99999 → 99999 |
| Cutout Size | 93 x 45 mm |
| Depth | 90mm |
| Measurement Range | -99999 → 99999 |
| Weight | 160g |
| Minimum Measurement | -99999 |
| Cutout Width | 93mm |
| Meter Type | Counter/Preset Counter |
| Minimum Operating Temperature | -10°C |
| Maximum Temperature | +60°C |
| Meter Accuracy | 0.1% |
| Cutout Height | 45mm |
| Maximum Operating Temperature | +60°C |
| Series | NE1218 |
Product Details
– Display 5 digits, LED 14 mm 3 colors red, green and amber
– Universal counting inputs NPN, PNP, Namur, TTL, in voltage 10-300 VAC or encoder 2×90°
– Functions MINI, MAXI in tachometer / frequency
– 3 programmable inputs
– 2 or 4 presets with relay or electronic outputs
– Analog output 4-20 mA or 0-10 V
– Serial interface RS232, RS485 or Ethernet interface
– Power supply voltage 85 to 260 VAC or 100 to 300 VDC 10,5 to 70 VDC or 21 to 53 VAC
– Universal counting inputs NPN, PNP, Namur, TTL, in voltage 10-300 VAC or encoder 2×90°
– Functions MINI, MAXI in tachometer / frequency
– 3 programmable inputs
– 2 or 4 presets with relay or electronic outputs
– Analog output 4-20 mA or 0-10 V
– Serial interface RS232, RS485 or Ethernet interface
– Power supply voltage 85 to 260 VAC or 100 to 300 VDC 10,5 to 70 VDC or 21 to 53 VAC
