Baumer PA420 LED Digital Panel Multifunction Meter for Current, Voltage, 93 mm x 45 mm | PA420.014AX01
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: PA420.014AX01
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Product Type | Digital Panel Multifunction Meter |
| Properties Measured | Current, Voltage |
| Display Type | LED |
| Cutout Height | 93mm |
| Depth | 150mm |
| Number of Digits | 5 |
| Cutout Width | 45mm |
| Digit Height | 14mm |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | UL 94 V-0 |
| Meter Type | Electrical |
| Series | PA420 |
| Maximum Measurement | 32000 |
Product Details
PA 420 series multi-function process indicators
Multi-function process indicators with input signal range ±10 Vdc, ±20 mA, potentiometer.
5, 10 and 24 V sensor excitation.
Easy programming using 5 keys on front panel.
14 mm red LED display.
Three versions: standard, two thresholds or two thresholds + analogue output.
27 pre-programmed functions accessible by 4logic inputs (functions:tare, min., max., hold, reset, etc.).
Frame linearisation (11).
