Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Sensor Style | Block |
| Detection Type | Retroreflective |
| Detection Range | 10 m |
| Output Type | PNP |
| Electrical Connection | M12 4 Pin Connector |
| Maximum DC Voltage | 30V |
| Light Source | Laser Light |
| IP Rating | IP67 |
| Maximum Current | 100 mA |
| Response Time | <250 μs |
| Minimum Operating Temperature | -10°C |
| Series | OPDK |
| Maximum Operating Temperature | +50°C |
| Housing Material | ASA, MABS |
Product Details
Retro-reflective Laser Sensor
Polarising filter
Light/dark operate
Reverse polarity
Repeat accuracy <0.1mm at laser focus
Distance to laser focus 400mm
Class 1 Laser
Wave length 650nm
Response time <0.25ms
Dimensions 43mm (H) x 14.8mm (W) x 31mm (D)
Operating temperature -10 → +50 °C
