Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Sensor Technology | Ultrasonic |
| Body Style | Block |
| Detection Range | 1 m |
| Analogue Switching Output Type | 0-10 V |
| Connection Type | M12 |
| Supply Voltage | 15 → 30 V dc |
| Length | 65mm |
| IP Rating | IP67 |
| Housing Material | Die Cast Zinc |
| Width | 30mm |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -10°C |
| Short Circuit Overload Protection | Yes |
| Switching Current | 20 mA |
| Maximum Operating Temperature | +60°C |
| Reverse Polarity Protection | Yes |
| Depth | 31.1mm |
Product Details
UNDK-30U Series Analogue Output
Repeatability < 1% Sd,
Teach-in
Output slope can be inverted
M12 plug-in connector
Dimension (mm): 65(excl conn.) x 30 x 31 HWD
LED indication
Short circuit and reverse polarity protection
IP67 ingress protection
