Baumer Ultrasonic Threaded Barrel Motion Sensor, M18, 1 m Detection 4-20 mA, 12 → 24 V dc | UR18.DA0.2-IAMJ.9SF
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: UR18.DA0.2-IAMJ.9SF
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Baumer |
| Thread Size | M18 |
| Sensor Technology | Ultrasonic |
| Body Style | Threaded Barrel |
| Detection Range | 1 m |
| Analogue Switching Output Type | 4-20 mA |
| Connection Type | M12 |
| Supply Voltage | 12 → 24 V dc |
| Length | 64mm |
| IP Rating | IP69 |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +65°C |
| Switching Current | 100 mA |
Product Details
The Baumer ultrasonic distance measuring sensor has 20 to 1000 mm measuring distance and has current output with qTeach, line-Teach, IO-Link . It used connector M12 which has 5 pin.
Operating temperature -25 to +65 °C
Protection class IP 69
Protection class IP 69
