binder Circular Connector, 12 Contacts, Cable, M12 Connector, Socket, Female, IP67, 713 Series | 99-0492-52-12

From Binder, the 713 series of M12 Euro style sensor sockets designed for cable mounting. The re-wireable circular connectors have a threaded mating mechanism with A coding, preventing incorrect mating. Along with an IP67 ingress rating, the 713 series of female compact connectors are best suited to environments that demand a more rugged connector solution. Can be attached to M12 single-ended cable assemblies to make up jumper cables and interconnecting leads.

• A coded, for sensors, DC power, and 1 G-bit Ethernet

• 3, 4, 5 and 12-way variants

• Straight or 90° cable entry

• IP67 ingress protection rating

• Gold plated brass contacts

• Internal screw termination

• A threaded mating mechanism for secure connection

• Re-wireable –no special tooling required

• Robust and compact design offering max performance

The 713 series of M12 connectors are best suited to industrial applications. They are generally used when connecting to sensors, actuators, and cylinders in the industrial field. Some of the most common areas are

• Factory automation

• Process Control

• Industrial automation and instrumentation

• Commercial electronics

• Food and Beverage

• Robotics

• Transportation

• Sensors and switches

The 713 female connectors are waterproof and have an IP67 ingress rating. This means they are dustproof and are protected from jets of water from all directions. Ideal for wash-downs and other similar harsh environments.

Q – How robust are the connectors?

A – The 713 series of M12 sockets are manufactured from high-grade engineering materials. They are strong, reliable

Q – Are the connectors easy to terminate?

A – Yes, this range of compact connectors have screw clamp terminals. So no special tooling is required.

Q – Are there any additional accessories?

A– There is a range of circular dust caps are available providing extra protection and maintaining the IP rating when the connectors are not in use.

Female dust caps for sockets 706-7429, 706-7423 and 706-7439
