binder Circular Connector, 2 Contacts, Cable, M9 Connector, Plug, Male, IP40, 711 Series | 99-0071-100-02

Name: binder Circular Connector, 2 Contacts, Cable, M9 Connector, Plug, Male, IP40, 711 Series | 99-0071-100-02
SKU: P8045-437
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 6 pcs

Mfr. Part No: 99-0071-100-02

Đánh giá: ⭐⭐⭐⭐⭐

SKU: P8045-437 Categories: binder, Industrial Circular Connectors

Description

Specifications

Attribute	Value
Brand	binder
Product Type	Circular Connector
Number of Contacts	2
Mount Type	Cable
Connector Size	M9
Current	4A
Plug/Socket	Plug
Contact Gender	Male
IP Rating	IP40
Orientation	Straight
Series	711
Voltage	125.0 V
Termination Type	Solder
Shell Size	11.5
Minimum Operating Temperature	-40°C
Mating Type	Screw-On
Maximum Operating Temperature	85°C
Housing Material	Metal
Standards/Approvals	No
Contact Plating	Gold
Contact Material	Brass

Product Details

Binder Circular Connector

The Binder 711 series 2-contacts, M9 male subminiature circular connector has a plug-type connection. This cable mount connector has a voltage rating of 125V and a current rating of up to 4A per contact. This connector is MADE of polyamide with gold-plated brass contacts. It supports a screw connector locking mechanism for sturdy mating attenuation and reliable contact.

Binder 711 – metal

The Series 711 subminiature round plugs are connectors of a simple design with very small dimensions and are protected to IP40. High reliability permits frequent connection and disconnection. Cable strain relief is achieved by a crimp ferrule.
