binder Circular Connector, 7 Contacts, Panel Mount, M16 Connector, Socket, Female, IP40, 680 Series | 09-0328-00-07

Name: binder Circular Connector, 7 Contacts, Panel Mount, M16 Connector, Socket, Female, IP40, 680 Series | 09-0328-00-07
SKU: 1462-511
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 5 pcs

Mfr. Part No: 09-0328-00-07

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 1462-511 Categories: binder, Industrial Circular Connectors

Description

Specifications

Attribute	Value
Brand	binder
Number of Contacts	7
Product Type	Circular Connector
Mount Type	Panel Mount
Current	5A
Connector Size	M16
Plug/Socket	Socket
Contact Gender	Female
IP Rating	IP40
Orientation	Straight
Series	680
Voltage	125.0 V
Termination Type	Solder
Minimum Operating Temperature	-40°C
Shell Size	18.5 mm
Maximum Operating Temperature	85°C
Housing Material	Die Cast Zinc
Standards/Approvals	No
Contact Plating	Silver
Contact Material	Brass

Product Details

Panel plug & socket

Featuring a straight body, this panel mount connector is miniature but robust. Ideal for solder termination it features silver contact plating with brass contact material. Binder 680 series connectors provide high reliability with simple assembly. Common use for these connectors include medical equipment, machine tool control, industrial automation and instrumentation.

Features and Benefits:

The use of Silver and Brass prevent oxidation and therefore provide durability and extend life expectancy. Multiple termination techniques are available due to the miniature size for panel mounting.
