binder Circular Connector, 8 Contacts, Panel Mount, M9 Connector, Socket, Female, IP40, 711 Series | 09-0482-00-08

Name: binder Circular Connector, 8 Contacts, Panel Mount, M9 Connector, Socket, Female, IP40, 711 Series | 09-0482-00-08
SKU: 4545-437
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 7 pcs

Mfr. Part No: 09-0482-00-08

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 4545-437 Categories: binder, Industrial Circular Connectors

Description

Specifications

Attribute	Value
Brand	binder
Product Type	Circular Connector
Number of Contacts	8
Mount Type	Panel Mount
Current	1A
Connector Size	M9
Plug/Socket	Socket
Contact Gender	Female
IP Rating	IP40
Series	711
Orientation	Straight
Voltage	125.0 V
Shell Size	11.5
Termination Type	Solder
Minimum Operating Temperature	-40°C
Mating Type	Screw-On
Maximum Operating Temperature	85°C
Housing Material	Metal
Standards/Approvals	No
Contact Plating	Gold
Contact Material	Bronze

Product Details

Subminiature Connector, Female Socket, M9, IP40 – Series 711

Series 711, M9, female socket, subminiature connector with screw locking and IP40 ingress protection. These M9 female sockets have solder terminations and the cable housings have integrated strain relief.

Binder 711 – Metal

The Series 711 subminiature round plugs are connectors of a simple design with very small dimensions and are protected to IP40. High reliability permits frequent connection and disconnection. Cable strain relief is achieved by a crimp ferrule.
