Bosch Rexroth, R900551703 Directional Spool, Type J 230 V | R900551703
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: R900551703
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bosch Rexroth |
| Number of Positions | 2 |
| Product Type | Directional Spool |
| Number of Ports | 4 |
| Solenoid Type | Double |
| Voltage | 230 V |
| Seal Material | Nitrile Rubber (NBR), Fluorelastomer |
| Series | 6x |
| Spool Type | Type J |
| Maximum Flow Rate | 60L/min |
| Valve Maximum Operating Pressure | 350 bar |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | NFPA T3.5.1 R2-2002 D03, EN ISO 13849, DIN EN 60529, DIN EN 175301-803, DIN 24340, IEC 60947-5-2, ISO 4401-03-02-0-05 |
Product Details
Solenoid Operated Directional Spool Valves, CETOP 3, Size 6
6X Series direct operating, spring return and detent directional control spool valves.
Solenoid operated by a 24Vdc or 110Vac power supply
Porting Pattern to CETOP 3 size 6 for subplate mounting
Wet pin dc or ac removable solenoids can be rotated through 90° to facilitate installation
Connections to DIN 24 340 Form A6 ISO 4401-AB-03-4-A
Emergency hand operation
Seal kit available separately
Coils can be replaced without releasing any fluid
Replacement solenoid coils 24Vdc and 110Vac are available separately
Note
Take care to prevent pressure intensification in single rod cylinders.
