Bosch Rexroth, R900561282 Directional Spool, DIN, Directional Spool 230 V | R900561282
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: R900561282
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bosch Rexroth |
| Number of Positions | 3 |
| Product Type | Directional Spool |
| Mount Pattern | DIN |
| Seal Material | Nitrile Butadiene Rubber |
| Voltage | 230 V |
| Solenoid Type | High-power wet-pin DC or AC solenoids with detachable coil |
| Series | 6x |
| Spool Type | Directional Spool |
| Maximum Flow Rate | 80L/min |
| Minimum Operating Temperature | 30°C |
| Valve Maximum Operating Pressure | 350 bar |
| Maximum Operating Temperature | 80°C |
| Standards/Approvals | DIN EN 60529, DIN EN 175301-803, DIN 24340, EN ISO 13849, ISO 4401-03-02-0-05, NFPA T3.5.1 R2-2002 D03 |
Product Details
Solenoid Operated Directional Spool Valves, CETOP 3, Size 6
6X Series direct operating, spring return and detent directional control spool valves.
Solenoid operated by a 24Vdc or 110Vac power supply
Porting Pattern to CETOP 3 size 6 for subplate mounting
Wet pin dc or ac removable solenoids can be rotated through 90° to facilitate installation
Connections to DIN 24 340 Form A6 ISO 4401-AB-03-4-A
Emergency hand operation
Seal kit available separately
Coils can be replaced without releasing any fluid
Replacement solenoid coils 24Vdc and 110Vac are available separately
Note
Take care to prevent pressure intensification in single rod cylinders.
