Bourdon Analogue Pressure Gauge 16bar Bottom Entry 100mm Outside Diameter, UKAS | MEX5D31B24
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: MEX5D31B24
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourdon |
| Maximum Pressure Measurement | 16bar |
| Mounting Type | Bottom Entry |
| Minimum Pressure Measurement | 0bar |
| Display Type | Analogue |
| Gauge Outside Diameter | 100mm |
| Best Accuracy | ± 1.0% |
| Case Material | Stainless Steel |
| Minimum Operating Temperature | -20°C |
| Calibrated | UKAS |
| Maximum Operating Temperature | +70°C |
Product Details
Baumer Industrial Pressure Gauges – Class 1.0
Stainless steel accuracy class 1.0 industrial pressure gauges with a black plastic pointer and easy to read white dial face with black lettering. The gauge is fitted with a high quality instrument glass window with an elastomer seal and blow out device for operator safety.
Features and benefits
• Suitable for corrosive gases and liquids
• EN 837-1 Class 1.0
• IP 65
• Stainless steel wetted parts
• Fully welded process connection
• 100 mm Nominal size
Applications
• Food and beverage
• Laboratory and medical
• Oil gas / chemical
• Water and waste water
• Energy
• Transportation and logistics
• Machinery
