Specifications
| Attribute | Value |
|---|---|
| Brand | Bourdon |
| Maximum Pressure Measurement | 25bar |
| Mounting Type | Back Entry |
| Minimum Pressure Measurement | 0bar |
| Display Type | Analogue |
| Gauge Outside Diameter | 63mm |
| Best Accuracy | ±1.6% |
| Case Material | Stainless Steel |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +70°C |
Product Details
Class 1.6 according to EN 837-1
Wetted parts: Stainless steel
Case with crimped bezel ring
Lloyds Register Approval
Option: Liquid-filled for applications with pulsations or vibrations
Option: Case material 1.4404 (316L) for aggressive atmosphere
