Bourns 0.35 A Resettable Fuse, 36 V | MF-MSHT035KX-2
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: MF-MSHT035KX-2
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Trip Current | 1.75A |
| Product Type | Resettable Fuse |
| Voltage | 36 V |
| Current Rating | 40 A |
| Time to Trip | 0.1s |
| Hold Current | 0.35A |
| Length | 4.83mm |
| Height | 0.85mm |
| Width | 3.41 mm |
| Terminal Material | Electroless Nickel Immersion Gold Plated |
| Minimum Resistance | 0.3Ω |
| Minimum Operating Temperature | -40°C |
| Maximum Resistance | 2.6Ω |
| Maximum Operating Temperature | 125°C |
| Power Dissipation | 1.2W |
| Standards/Approvals | TUV, RoHS, UL, AEC-Q200 |
| Package Size | 1812 |
| Series | MF-MSHT |
| Package Type | Surface Mount |
Product Details
The Bourns MF-MSHT series is PTC Resettable Fuse are designed for the protection of electrical and electronic circuits against excessive currents. They switch rapidly from a low resistance to very high resistance state under electrical overload or short circuit conditions, and feature automatic reset and return to low resistance state when fault condition ceases and power is removed. It has resettable fault protection for industrial transportation, communication, security, and consumer electronic equipment.
Operating temperature range from -40 °C to 125 °C
Surface mount packaging for automated assembly
Low thermal derating factor
