Bourns 0.75 A Resettable Fuse, 6 V | MF-PSMF075X-2
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: MF-PSMF075X-2
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Resettable Fuse |
| Trip Current | 1.5A |
| Voltage | 6 V |
| Current Rating | 40 A |
| Time to Trip | 0.2s |
| Hold Current | 0.75A |
| Length | 2.3mm |
| Height | 1.25mm |
| Width | 1.5 mm |
| Terminal Material | Gold Plated Nickel |
| Minimum Resistance | 0.09Ω |
| Minimum Operating Temperature | 85°C |
| Maximum Resistance | 350mΩ |
| Power Dissipation | 0.6W |
| Maximum Operating Temperature | -40°C |
| Standards/Approvals | UL, RoHS |
| Package Size | 0805 |
| Series | MF-PSMF |
| Package Type | Reel |
Product Details
MF-PSMF Series
Applications include USB port protection – On the Go and 2.0, PC motherboards – Plug and Play protection, mobile phones – battery and port protection, PDAs/digital cameras, game console port protection.
Compact design to save board space – 0805 footprint
Small size results in very fast time to react to fault events
Low profile
Surface Mount Technology
Resettable fuses are designed for the protection of electrical and electronic circuits against excessive currents. They switch rapidly from a low resistance to very high resistance state under electrical overload or short circuit conditions, and feature automatic reset and return to low resistance state when fault condition ceases and power is removed.
Maintenance free automatic reset for thousands of cycles
Small size and no fuseholder required
Main applications
Security systems
Power supplies and transformers
Power switching devices
Automotive and medical equipment
Instrumentation and control
Computers and peripherals
Audio Visual and telecommunications
Approvals
UL
