Bourns 1-Element Bi-Directional TVS Diode, 2-Pin Surface Mount | PTVS10-086C-M
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: PTVS10-086C-M
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | TVS Diode |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 96V |
| Mount Type | Surface |
| Package Type | Surface Mount |
| Maximum Reverse Stand-off Voltage Vwm | 86V |
| Pin Count | 2 |
| ESD Protection | Yes |
| Minimum Operating Temperature | -55°C |
| Clamping Voltage VC | 157V |
| Maximum Peak Pulse Current Ippm | 10kA |
| Maximum Operating Temperature | 125°C |
| Number of Elements per Chip | 1 |
| Height | 7.24mm |
| Length | 16.05mm |
| Series | PTV |
| Standards/Approvals | No |
| Width | 14.6 mm |
| Automotive Standard | No |
Product Details
The Bourns® Model PTVS10-086C-M high current bidirectional TVS diode is designed for use in high power DC bus clamping applications.
10 kA, 8/20 μs surge capability
1 kA, 10/350 μs surge capability
Low clamping voltage under surge
Bidirectional TVS
Surface mount package
Applications
High Power DC Protection
