Bourns 1-Element Bi-Directional TVS Diode, 400 W, 2-Pin DO-214 | SMAJ12CA
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: SMAJ12CA
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Diode Configuration | Single |
| Product Type | TVS Diode |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 13.3V |
| Mount Type | Surface |
| Package Type | DO-214 |
| Maximum Reverse Stand-off Voltage Vwm | 12V |
| Pin Count | 2 |
| Peak Pulse Power Dissipation Pppm | 400W |
| Test Current It | 1mA |
| Minimum Operating Temperature | -55°C |
| Maximum Peak Pulse Current Ippm | 35A |
| ESD Protection | Yes |
| Maximum Operating Temperature | 150°C |
| Number of Elements per Chip | 1 |
| Height | 2.42mm |
| Width | 2.92 mm |
| Standards/Approvals | No |
| Series | SMA |
| Length | 4.57mm |
| Maximum Reverse Leakage Current | 5μA |
| Automotive Standard | AEC-Q101 |
Product Details
SMBJ Series 400W TVS Diodes, Bidirectional
Bidirectional Transient Voltage Suppressor diodes with 400W peak pulse capacity in compact DO214AB (SMB) surface mount packages.
Transient Voltage Suppressors, Bourns Electronics
