Bourns 1 Output Surface PCB Transformer, AEC-Q, RoHS 20 W | PCS020-EE0503KS
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: PCS020-EE0503KS
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | PCB Transformer |
| Number of Outputs | 1 |
| Length | 8mm |
| Width | 8.13 mm |
| Depth | 5.3mm |
| Power | 20W |
| Mount Type | Surface |
| Isolation Voltage | 500Vrms |
| Minimum Operating Temperature | -40°C |
| PCB Transformer Current | 20A |
| Maximum Operating Temperature | 125°C |
| Series | PCS020 |
| Minimum Operating Frequency | 10kHz |
| Standards/Approvals | AEC-Q, RoHS |
| Maximum Operating Frequency | 1MHz |
Product Details
The Bourns PCS series current sense transformer is suitable for frequency up to 1 MHz. It has 500 Vrms isolation between windings. It is suitable for switched-mode power supplies, motor control, overload sensing, and AC current applications.
Rated current on primary up to 20 A
Operating temperature range from 40 °C to 125 °C
