Bourns 3 A Resettable Fuse, 30 V | MF-R300
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: MF-R300
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Resettable Fuse |
| Trip Current | 6A |
| Voltage | 30 V |
| Time to Trip | 10.8s |
| Current Rating | 40 A |
| Hold Current | 3A |
| Length | 12mm |
| Height | 18.3mm |
| Width | 3 mm |
| Minimum Resistance | 0.02Ω |
| Maximum Resistance | 80mΩ |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 85°C |
| Power Dissipation | 2W |
| Standards/Approvals | UL, RoHS |
| Lead Diameter | 0.81mm |
| Lead Orientation | Radial |
| Series | MFR |
Product Details
MF-R Series
Radial leaded devices
Rated at 40A except MF-R1100 which is rated at 100A
Cured, flame retardant epoxy polymer insulating material meets UL 94V-0 requirements
PCB Wire Ended
All are UL, CSA, TUV approved
Protection of electrical and electronic circuits against excessive currents
Rapid switch from low resistance state to very high resistance with electrical overload or short circuit
Quick and automatic reset and return to low resistance state when fault condition corrected and power removed
Features:
Automatically resets itself thousands of times
Maintenance free
Small size and no fuseholder required
Main applications:
Security systems
Power supplies and transformers
Power switching devices
Automotive and medical equipment
Instrumentation and control
Computers and peripherals
Audio visual and telecommunications
