Bourns 5 V dc 128 ppr Pulse Optical Encoder with a 6.35 mm Round Shaft, Bracket Mount | ENA1J-B28-L00128L
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: ENA1J-B28-L00128L
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Pulses Per Revolution | 128ppr |
| Product Type | Optical Encoder |
| Encoder Signal | Digital Square Wave |
| Supply Voltage | 5 V dc |
| Shaft Diameter | 6.35mm |
| Automotive Standard | No |
| Shaft Length | 22.23mm |
| Mounting Hole Diameter | 9.5 mm |
| Mount Type | Bracket Mount |
| Shaft Style | Round |
| Maximum Operating Speed | 3000rpm |
| Encoder Type | Incremental |
| Series | EN |
| Standards/Approvals | RoHS |
| Current Rating | 26 mA |
Product Details
EN Series Rotary Optical Encoder
EN series rotary optical encoders with two channel quadrature output, a square wave signal and a resolution to 256 PPR. These EN series rotary optical encoders are bushing or servo mount, CMOS and TTL compatible and have a long life of 10,000,000 revolutions. Versions with a ball bearing bushing configuration (stock numbers 164-2633, 789-9501, 789-9501 and 827-5029) have an increased life of 200,000,000 revolutions as well as a high operating speed of 3000 rpm. Typical applications for these rotary optical encoders include digital panel control or position sensing where reliability, long life, high resolution and precision linearity are essential.
Features & Benefits
2-bit quadrature output, channel A leads channel B by 90° with clockwise rotation
Metal bushing and shaft, long life, high operating speed
Square wave signal, CMOS and TTL compatible
64, 128 or 256 cycles per revolution
ENA types have bush mounting (spring loaded for optimum feel)
ENS type has bush mounting (ball bearing shaft support)
Continuous mechanical rotation
Product Application Information
Typical applications for these rotary optical encoders include digital panel control or position sensing where reliability, long life, high resolution and precision linearity are essential.
