Bourns 600 V 2 A Diode Rectifier Diode 2-Pin DO-214AA | CD214B-S2J
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: CD214B-S2J
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Diode |
| Mount Type | Surface |
| Package Type | DO-214AA |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Series | CD214 |
| Rectifier Type | Rectifier Diode |
| Pin Count | 2 |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 0.96V |
| Minimum Operating Temperature | -65°C |
| Maximum Operating Temperature | 175°C |
| Length | 5.2mm |
| Width | 3.6 mm |
| Standards/Approvals | No |
| Height | 1.2mm |
| Automotive Standard | AEC-Q101 |
Product Details
The Glass Bourns CD214B-S2J passivated Rectifier Diodes offer a forward current of 2 A with a choice of repetitive peak reverse voltage of 600 V .Maximum Average Forward Current IF(AV) 2 A.
RoHS compliant
Low profile
Low power loss, high efficiency
UL 94V-0 rating
Halogen free
