Bourns Absolute Pressure SensorManifold 3 | BPS130-HA100P-1SG
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: BPS130-HA100P-1SG
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Absolute Pressure Sensor |
| Sensor Type | Absolute Pressure Sensor |
| Mount Type | Manifold |
| Pin Count | 3 |
| Minimum Supply Voltage | 4.5V |
| Maximum Operating Pressure | 100 psi |
| Maximum Supply Voltage | 5.5V |
| Accuracy | 0.25 %FS |
| Port Type | Single |
| Maximum Operating Temperature | 150°C |
| Width | 10.3 mm |
| Length | 12.8mm |
| Height | 1mm |
| Series | BPS130 |
| Standards/Approvals | RoHS Compliant |
| Minimum Operating Pressure | 0psi |
| Minimum Operating Temperature | -40°C |
| Automotive Standard | No |
Product Details
BPS pressure sensors are based on innovative MEMS technology which provides extremely accurate condition readings in a miniature package size. The sensing element is comprised of embedded piezoresistive elements bonded to a chemically etched silicon diaphragm.
Compensated output
Direct-media monitoring
Gauge and absolute types
Isolated on board electronics
Gold-plated Kovar™ port option
Applications
Industrial:
Refrigerant systems
Water level & pressure monitoring
Medical Devices(low/medium risk):
Diagnostic/analysis equipment
Heavy Equipment:
Oil & fuel systems
Exhaust gas pressure sensing
