Bourns Analogue Low Pressure SensorSurface 8 Surface Mount | BPS110-AD01P0-2DG
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: BPS110-AD01P0-2DG
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Analogue Low Pressure Sensor |
| Sensor Type | Gauge Pressure Sensor |
| Maximum Overload Pressure | 1psi |
| Mount Type | Surface |
| Package Type | Surface Mount |
| Pin Count | 8 |
| Minimum Supply Voltage | 2.7V |
| Maximum Operating Pressure | 1 psi |
| Port Type | Horizontal, Dual |
| Maximum Supply Voltage | 5.5V |
| Accuracy | 0.25 %FS |
| Maximum Operating Temperature | 85°C |
| Standards/Approvals | RoHS3 Directive 2015/863 |
| Width | 8.4 mm |
| Maximum Output Voltage | 4.5V |
| Length | 12.7mm |
| Series | BPS110 |
| Height | 3.6mm |
| Minimum Operating Pressure | 0.15psi |
| Automotive Standard | No |
| Minimum Output Voltage | 0.5V |
| Minimum Operating Temperature | -40°C |
Product Details
Ultra-low sensing: 0.15 PSI to 1.0 PSI (10 mbar to 70 mbar)
Extreme sensitivity and stability: Total Error Band of 1.5 % FS over a temperature range of 0 °C to +60 °C (Six-Sigma process)
Lifetime drift: 0.5 % FS
Media compatibility: non-corrosive dry gases
Analog and digital (I2C) output options
Differential and gauge options
Active temperature compensation
Superior performance in ultra-low pressure sensing applications
Design flexibility – for use in either analog or digital systems
Compensated plug and play reduces development time
World-class technical support
Global supply chain
Medical Devices (low/medium risk)
Applications
Portable oxygen generators
Nebulizer
CPAP equipment
Diagnostic spirometer
Gas chromatography equipment
Facility ventilation pressure
Idustrial
Process control
HVAC
Pneumatic control
Gas flow instrumentation
Flow calibrators
Consumer
Home Appliances
