Bourns, CC453232A, 1812 Multilayer Surface Mount Inductor with a Ferrite Core, 100 μH Ferrite Core ±10 % 280 mA Idc Q:30 | CC453232A-101KL
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: CC453232A-101KL
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Multilayer Surface Mount Inductor |
| Inductance | 100 μH |
| Maximum DC Current | 280mA |
| Package/Case | 1812 |
| Length | 4.5mm |
| Packaging | Tape & Reel |
| Automotive Standard | AEC-Q200 |
| Minimum Operating Temperature | -40°C |
| Maximum DC Resistance | 4Ω |
| Inductance Tolerance | ±10 % |
| Maximum Operating Temperature | 150°C |
| Series | CC453232A |
| Height | 3.2mm |
| Standards/Approvals | RoHS |
| Depth | 3.2mm |
| Termination Style | Solder |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 5.5MHz |
| Inductor Construction | Ferrite Core |
| Minimum Quality Factor | 30 |
Product Details
The Bourns Electronics Chip Inductors comes with Ferrite core material, Epoxy resin enclosure and stannum terminal material. This inductor is resistance to mechanical shock and pressure and has a tight dimension tolerances for automatic placement.
Inductance drops 10% at saturation current
-40°C to +150°C operating temperature
Enameled copper wire
