Bourns Surface Audio Transformer | SM-LP-5001E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: SM-LP-5001E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | Audio Transformer |
| Primary Impedance | 600Ω |
| Primary DC Resistance | 115Ω |
| Secondary DC Resistance | 115Ω |
| Mount Type | Surface |
| Termination Type | Solder |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 85°C |
| Length | 12.8mm |
| Depth | 9mm |
| Width | 7.5 mm |
| Series | SM-LP-5001 |
| Standards/Approvals | UL 60950, RoHS |
| Minimum Operating Frequency | 200Hz |
| Maximum Operating Frequency | 4kHz |
| Isolation Voltage | 1.5kV |
| Construction | Encapsulated |
| Turns Ratio | 1:1 |
Product Details
Bourns SM-LP-5001 Series Surface Mount Line Matching Transformers
SM-LP-5001 line matching transformers from Bourns are a subminiature solution, with a seated height of only 7.5 mm. These line matching transformers are vacuum encapsulated and have low distortion of only 0.015%.
600 Ω nominal impedance
80 dB minimum balance
-76 dB maximum distortion at 600 Hz
2000 Vrms dielectric strength for 1 minute
Product Application Information
Suitable applications for these line matching transformers include instrumentation, telecommunications, laptops and modems (V32).
