Bourns Surface LAN Ethernet Transformer, 125 °C, -40 °C 6.1 mm | SM91076L-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: SM91076L-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Bourns |
| Product Type | LAN Ethernet Transformer |
| Number of Outputs | 1 |
| Insertion Loss | -1.4dB |
| Mount Type | Surface |
| Depth | 6.1mm |
| Inductance | 350 μH |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 125°C |
| Series | SM91076L |
| Termination Type | Tin |
| Turns Ratio | 1 : 1 ± 2 |
| Standards/Approvals | MECHATROLINK-III, RoHS, IEEE 802.3u (100Base-T), IEC 61000-4-5 |
| Supported Ethernet Standards | 10/100 Base-T |
Product Details
The Bourns Electronics Base-T Transformer comes with additional metal shield for surge immunity and superior EMC performance and Hi-Pot voltage rating of 2250 VDC or 1500 VAC.
0.5μH maximum leakage inductance
-40°C to +125°C operating temperature
