Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Display Type | 7 Segment |
| Product Type | LED Display |
| Number of Characters | 1 |
| LED Colour | Red |
| Number of Segments | 7 |
| Dominant Wavelength | 632 nm |
| Character Width | 4.6mm |
| Character Height | 7mm |
| Common Connection | Cathode |
| Mount Type | Surface Mount |
| External Width | 7.5mm |
| External Height | 3.8mm |
| External Depth | 10.8mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 105°C |
| Luminous Intensity | 7.5mcd |
| Colour of Face | Grey |
| Standards/Approvals | RoHS |
| Forward Voltage | 2V |
| Power Dissipation | 65mW |
| Decimal Orientation | Right Side |
| Forward Current | 25mA |
Product Details
Single-digit 7-segment Red LED Displays
Broadcom 7-Segment LED Displays
