Broadcom 1 Axis Surface Sensor 3 V 5.5 V, SSI, SPI, QFN-24, 24-Pin | AEAT-9933-102

Name: Broadcom 1 Axis Surface Sensor 3 V 5.5 V, SSI, SPI, QFN-24, 24-Pin | AEAT-9933-102
SKU: P249-722
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: AEAT-9933-102

Đánh giá: ⭐⭐⭐⭐⭐

SKU: P249-722 Categories: Broadcom, Motion Sensor ICs

Description

Specifications

Attribute	Value
Brand	Broadcom
Product Type	Sensor
Sensor Type	Magnetic Rotary Encoder
Number of Axis	1
Technology	Rotary Encoder
Mount Type	Surface
Interface Type	SSI, SPI
Magnetic Type	Bipolar
Maximum Frequency Response	1MHz
Minimum Supply Voltage	3V
Maximum Supply Voltage	5.5V
Package Type	QFN-24
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	125°C
Pin Count	24
Standards/Approvals	RoHS
Height	4mm
Series	AEAT9933
Width	4 mm
Length	4mm
Supply Current	25mA
Automotive Standard	No

Product Details

The Broadcom Angular magnetic rotary sensor that provides accurate angular measurement over a full 360 degrees of rotation. It is a sophisticated system that uses integrated Hall sensor elements with complex analogue and digital signal processing within a single device. A simple two pole magnet generates the necessary magnetic field by rotating it in perpendicular.

Commutation angle output UVW 1pp to 32pp

PWM output modes

Programmable hysteresis

Compact QFN-24 leads package

RoHS compliant

INL angle correction for high accuracy
