Broadcom 1 LED LED Display Cathode Green 5mcd Right Side 5.1 mm | HDSM-203H
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: HDSM-203H
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Display Type | LED |
| Product Type | LED Display |
| Number of Characters | 1 |
| LED Colour | Green |
| Number of Segments | 7 |
| Dominant Wavelength | 572 nm |
| Character Width | 3.2mm |
| Character Height | 5.1mm |
| Common Connection | Cathode |
| Mount Type | Surface |
| External Depth | 2.8mm |
| External Width | 5.76mm |
| External Height | 10mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 105°C |
| Luminous Intensity | 5mcd |
| Standards/Approvals | RoHS |
| Colour of Face | Grey |
| Power Dissipation | 65mW |
| Series | HDSM |
| Decimal Orientation | Right Side |
| Forward Current | 25mA |
Product Details
The Broadcom LED Display is a single digit surface mount display uses which AlInGaP chip technology. The grey top surface and white segments provide optimum contrast. This device is available in common cathode configuration. To facilitate easy pick and place assembly, the LED displays are packed in tape and reel form.
RoHS compliant
JEDEC MSL 3 standard
Low current operation
Excellent character appearance
