Broadcom 1 LED LED Display Cathode Yellow 10mcd Right Side 5.1 mm | HDSM-203F
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: HDSM-203F
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | LED Display |
| Display Type | LED |
| Number of Characters | 1 |
| LED Colour | Yellow |
| Number of Segments | 7 |
| Dominant Wavelength | 590 nm |
| Character Width | 3.2mm |
| Character Height | 5.1mm |
| Common Connection | Cathode |
| Mount Type | Surface |
| External Height | 10mm |
| External Depth | 2.8mm |
| External Width | 5.76mm |
| Minimum Operating Temperature | -40°C |
| Luminous Intensity | 10mcd |
| Maximum Operating Temperature | 105°C |
| Colour of Face | Grey |
| Standards/Approvals | RoHS |
| Power Dissipation | 65mW |
| Forward Current | 25mA |
| Series | HDSM |
| Decimal Orientation | Right Side |
Product Details
The Broadcom LED Display is a single digit surface mount display uses which AlInGaP chip technology. The grey top surface and white segments provide optimum contrast. This device is available in common cathode configuration. To facilitate easy pick and place assembly, the LED displays are packed in tape and reel form.
RoHS compliant
JEDEC MSL 3 standard
Low current operation
Excellent character appearance
