Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Optical Encoder |
| Pulses Per Revolution | 1024ppr |
| Encoder Signal | 2 Channel Quadrature with Index Pulse |
| Supply Voltage | 4.5/5.5 V |
| Shaft Diameter | 8mm |
| Automotive Standard | No |
| Shaft Length | 14mm |
| Mount Type | Standard, External |
| Shaft Style | Hollow |
| Termination Style | 5 x 0.025 Inch Square Pin on 0.1 Inch Centre |
| Maximum Operating Speed | 30000rpm |
| Standards/Approvals | RoHS6 |
| Current Rating | 5 mA |
Product Details
HEDS-9000/9100 – Two Channel Optical Incremental Encoder Modules
