Broadcom 4.5 to 5.5 V Optical Encoder, Surface Mount | AEDR-8000-1K2
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: AEDR-8000-1K2
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Optical Encoder |
| Encoder Signal | 2 Channel Quadrature |
| Supply Voltage | 4.5 to 5.5 V |
| Automotive Standard | No |
| Mount Type | Surface Mount |
| Standards/Approvals | JESD22-A115-A Class B, ESD JESD22-A114-A Class 2 |
| Series | AEDR-8000 |
| Current Rating | 8 mA |
Product Details
AEDR-8000 Series – Reflective Surface Mount Optical Encoder
• Reflective technology
• Surface mount small outline leadless package
• Direct replacement of HEDR-8000 encoder
• Single channel incremental output
• Two channels quadrature outputs for direction
sensing
• Single 5 V supply, TTL compatible output
• -20°C to 85°C absolute operating temperature
• Lead-free package
• Encoding resolution options:
75, 150 and 180 (lines/inch) or 2.95, 5.91, 7.09
(lines/mm)
• PCB height profile options:
1.0 mm PCB thickness 1.5 mm PCB thickness
