Broadcom AELT-8000-S102 4-Channel Differential Line Driver, 3 State, Inverting, Non-Inverting, 16-Pin SOIC-16 | AELT-8000-S102
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: AELT-8000-S102
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Differential Line Driver |
| Logic Function | CMOS, TTL |
| IC Type | Line Driver |
| Number of Channels | 4 |
| Input Type | Buffered |
| Output Type | 3 State |
| Polarity | Inverting, Non-Inverting |
| Mount Type | Surface |
| Package Type | SOIC-16 |
| Minimum Supply Voltage | 4.5V |
| Pin Count | 16 |
| Maximum Supply Voltage | 36V |
| Maximum High Level Output Current | 300mA |
| Maximum Propagation Delay Time @ CL | 175ns |
| Minimum Operating Temperature | -40°C |
| Maximum Low Level Output Current | 300mA |
| Maximum Operating Temperature | 125°C |
| Length | 10mm |
| Standards/Approvals | RoHS, MSL 1 |
| Series | AELT-8000 |
| Height | 4.32mm |
| Automotive Standard | No |
Product Details
The Broadcom High Voltage Quad Differential Output Line Driver IC is an industrial power line driver featuring four identical short circuit proof differential line drivers, capable of handling up to 36V of driver supply with a joint enable function, and operating at a maximum frequency of up to 5 MHz.
Short circuit proof tri state outputs
Low propagation delay
High Impedance CMOS compatible and TTL compatible
Over temperature protection circuit
Under voltage monitoring
