Broadcom AELT-8000-S16 4-Channel Differential Line Driver, 3 State, Inverting, Non-Inverting, 16-Pin SOIC-16 | AELT-8000-S16
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: AELT-8000-S16
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Differential Line Driver |
| Logic Function | CMOS, TTL |
| Number of Channels | 4 |
| IC Type | Line Driver |
| Input Type | Buffered |
| Output Type | 3 State |
| Polarity | Inverting, Non-Inverting |
| Mount Type | Surface |
| Package Type | SOIC-16 |
| Minimum Supply Voltage | 4.5V |
| Pin Count | 16 |
| Maximum High Level Output Current | 300mA |
| Maximum Supply Voltage | 36V |
| Minimum Operating Temperature | -40°C |
| Maximum Propagation Delay Time @ CL | 175ns |
| Maximum Low Level Output Current | 300mA |
| Maximum Operating Temperature | 125°C |
| Series | AELT-8000 |
| Width | 4 mm |
| Height | 4.32mm |
| Length | 10mm |
| Standards/Approvals | MSL 1, RoHS |
| Supply Current | 30mA |
| Automotive Standard | No |
Product Details
The Broadcom High Voltage Quad Differential Output Line Driver IC is an industrial-power line driver featuring four identical short circuit proof differential line drivers, capable of handling up to 36V of driver supply with a joint enable function, and operating at a maximum frequency of up to 5 MHz.
Over-temperature protection circuit
Under voltage monitoring
Short circuit-proof tri state outputs
High Impedance CMOS compatible and TTL compatible
