Broadcom ASSR-4118 Series Solid State Relay, 0.1 A Load, Surface Mount, 400 V Load, 1.6 V Control | ASSR-4118-503E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: ASSR-4118-503E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Maximum Load Current | 0.1 A |
| Mounting Type | Surface Mount |
| Maximum Load Voltage | 400 V |
| Minimum Load Voltage | -400 V |
| Minimum Control Voltage | 1.1 V |
| Maximum Control Voltage | 1.6 V |
| Switching Type | AC |
| Control Voltage Range | 1.1 → 1.6 V |
| Number of Poles | 1 |
| Contact Configuration | SPST |
| Terminal Type | PCB Pin |
| Output Device | MOSFET |
| Relay Type | Solid State Relay |
| Package Style | SO |
| Maximum Turn On Time | 5ms |
| Load Voltage Range | -400 → +400V |
| Series | ASSR-4118 |
| Dimensions | 4.4 x 4.3 x 2mm |
| Special Features | CMOS Compatibility, CSA Component Acceptance |
| Height | 2mm |
| Off State Leakage Current | 1 μA |
| Maximum Operating Temperature | +85°C |
| Depth | 4.3mm |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
| Capacitance | 0.4pF |
| Length | 4.4mm |
Product Details
Microchip Technology RF Receiver
The Broadcom ASSR-4118 series, SO-4 package single pole single throw (SPST) solid-state relay (Photo MOSFET) has an electric rating of 0.1A and 400V. It consists of an AlGaAs infrared light-emitting diode (LED) input stage optically coupled to a high voltage output detector circuit. The detector consists of a high-speed photovoltaic diode array and driver circuitry to switch ON/OFF two discrete high voltage MOSFETs.
Features and Benefits
• Compact solid-state bi-directional signal switch
• High input-to-output insulation voltage
• Low input current: CMOS compatibility
• Low on-resistance: 8ohm typical for DC only, 25ohm typical for AC/DC
• Operating temperature ranges between -40°C and 85°C
• Single channel
• High input-to-output insulation voltage
• Low input current: CMOS compatibility
• Low on-resistance: 8ohm typical for DC only, 25ohm typical for AC/DC
• Operating temperature ranges between -40°C and 85°C
• Single channel
Applications
• Telecommunication Switching
• Data Communications
• Industrial Controls
• Medical
• Security
• EMR/Reed Relay Replacement
• Data Communications
• Industrial Controls
• Medical
• Security
• EMR/Reed Relay Replacement
