Broadcom Hall Effect Sensor Surface, Voltage Output, Square Body, 3.3 V 3.3 V | ACHS-7225-500E

Name: Broadcom Hall Effect Sensor Surface, Voltage Output, Square Body, 3.3 V 3.3 V | ACHS-7225-500E
SKU: P5316-182
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 4 pcs

Mfr. Part No: ACHS-7225-500E

Đánh giá: ⭐⭐⭐⭐⭐

SKU: P5316-182 Categories: Broadcom, Hall Effect Sensors

Description

Specifications

Attribute	Value
Brand	Broadcom
Product Type	Hall Effect Sensor
Output Type	Voltage
Body Style	Square
Terminal Type	Surface Mount
Mount Type	Surface
Maximum DC Voltage	3.3V
Maximum Supply Voltage	3.3V
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Length	100mm
Width	69.85 mm
Maximum Operating Temperature	70°C

Product Details

The Broadcom fully integrated hall effect based isolated linear current sensor device family designed for AC or DC current sensing in industrial, commercial and communications systems. Applied current flowing through this copper conduction path generates a magnetic field that the hall IC converts into a proportional voltage. Device accuracy is optimized through the close proximity of the magnetic signal to the differential hall transducers.

Output voltage proportional to AC or DC currents

Ratiometric output from supply voltage

Factory trimmed for accuracy

Extremely stable output offset voltage

Near zero magnetic hysteresis
