Broadcom HFBR-2523Z 0.04 MBd 600 nm Fibre Optic Receiver, Round, H Push-in Connector | HFBR-2523Z
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: HFBR-2523Z
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Product Type | Fibre Optic Receiver |
| Maximum Data Rate | 0.04MBd |
| Connector Shape | Round |
| Wavelength of Peak Sensitivity | 600nm |
| Typical Rise Time | 13ns |
| Typical Fall Time | 10ns |
| Number of Pins | 6 |
| Mount Type | Through Hole |
| Connector Type | H Push-in |
| Height | 7.62mm |
| Length | 18.8mm |
| Standards/Approvals | No |
| Width | 12.19 mm |
| Series | HFBR |
| Output Signal Type | TTL |
Product Details
HFBR-0500Z Series Fibre Optic Connection
The HFBR-x5xxZ family, from Avago Technologies, form a part of the Versatile Link series. They are fibre optic link components including transmitters, receivers, connectors and cables. The HFBR-x5xxZ series are suitable solutions for problems with voltage isolation and insulation, EMI/RFI immunity or data security.
This family of devices consists of a variety of package configurations and connectors, providing a range of mechanical design solutions for the necessary application requirements.
The HFBR-x5xxZ transmitters use a 660nm LED for easy visibility. The receivers include a monolithic DC coupled, digital IC receiver with open collector Schottky output transistor.
The HFBR-x5xxZ series are ideal for a wide variety of applications including; motor controller triggering, data communications, local area networks and noise immune communication in audio and video equipment.
Features of the HFBR-x5xxZ series:
– Fibre optic components
– Enhanced digital links: dc-5 MBd
– Extended distance links: up to 120m at 40kBd
– Low current link: 6mA peak supply current
– Horizontal and vertical mounting
– Interlocking feature
– High noise immunity
– Easy connecting: simplex, duplex and latching connectors
– Flame retardant
– Compatible with standard TTL circuitry
Fibre Optics, Avago Technologies
