Broadcom Light Bar LED Display Red 45mcd | HLMP-2350
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: HLMP-2350
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| Display Type | Light Bar |
| Product Type | LED Display |
| LED Colour | Red |
| Number of Segments | 1 |
| Dominant Wavelength | 626 nm |
| Mount Type | Through Hole |
| External Height | 5mm |
| External Depth | 6.2mm |
| External Width | 20.3mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 85°C |
| Luminous Intensity | 45mcd |
| Standards/Approvals | RoHS |
| Colour of Face | White |
| Forward Voltage | 2V |
| Power Dissipation | 37mW |
| Forward Current | 25mA |
Product Details
Broadcom HLCP-X100 and HLMP-2XXX Light Bar Arrays
The HLCP-X100 and HLMP-2XXX range of LED light bars are available in a range of sizes and colours. These LED light bars are ideal for applications which require a bright and uniform light.
HLCP-X100 and HLMP-2XXX light bars have either single or segmented light emitting areas which offer a good on-off contrast. Suitable applications for the HLCP-X100 and HLMP-2XXX light bars include; telecommunications indicators, front panel status indicators and bar graphs.
Features of the HLCP-X100 and HLMP-2XXX LED light bars:
Rectangular LES (single or segment)
Uniform light emitting area
X-Y stackable
Flush mountable
Broadcom Light Bar Arrays
Caution
Observe Anti-static precautions when handling devices.
