Broadcom1.6 V Red LED 5mm Through Hole, HLMP-D155 | HLMP-D155
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: HLMP-D155
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| LED Colours | Red |
| Package Type | 5mm (T-1 3/4) |
| Mounting Type | Through Hole |
| Number of LEDs | 1 |
| Forward Voltage | 1.6 V |
| Luminous Intensity | 10 mcd |
| Number of Pins | 2 |
| Viewing Angle | 24 ° |
| Lens Shape | Round |
| Dominant Wavelength | 637 nm |
| Lens Colour | Clear |
| Dimensions | 5 x 9.19mm |
Product Details
Avago HLMP-D150/D155/K150/K155 Series LEDs
The HLMP-D150/D155 and HLMP-K150/K155 series, from Avago Technologies, are low current red LED lamps. They are solid state LED lamps which use double heterojunction (DH) AlGaAs/GaAs material technology. This material gives this family of LEDs a high light output efficiency at very low drive currents. They come in a deep red colour with a dominant wavelength of 637 nanometers.
The HLMP-D150/D155 and HLMP-K150/K155 LEDs are ideal for applications where a high light output is required with minimum power. Suitable applications for this family of LEDs include; low power circuits, battery powered equipment and telecommunication indicators.
The HLMP-D150/D155 and HLMP-K150/K155 LEDs are ideal for applications where a high light output is required with minimum power. Suitable applications for this family of LEDs include; low power circuits, battery powered equipment and telecommunication indicators.
Features of the HLMP-D150/D155 and HLMP-K150/K155 LEDs:
– HLMP-D150/D155: T-1 3/4 (5mm) package
– HLMP-K150/K155: T-1 (3mm) package
– Minimum luminous intensity specified at 1mA
– Wide viewing angle
– Low power
– Low forward voltage
– CMOS/MOS compatible
– TTL compatible
– Deep red colour
– HLMP-D150/D155: T-1 3/4 (5mm) package
– HLMP-K150/K155: T-1 (3mm) package
– Minimum luminous intensity specified at 1mA
– Wide viewing angle
– Low power
– Low forward voltage
– CMOS/MOS compatible
– TTL compatible
– Deep red colour
Visible Light LEDs, Avago Technologies
