Broadcom1.8 V Red LED 3mm Through Hole, HLMP-K101 | HLMP-K101
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: HLMP-K101
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| LED Colours | Red |
| Package Type | 3mm (T-1) |
| Mounting Type | Through Hole |
| Number of LEDs | 1 |
| Forward Voltage | 1.8 V |
| Luminous Intensity | 45 mcd |
| Number of Pins | 2 |
| Viewing Angle | 60 ° |
| Lens Shape | Round |
| Dominant Wavelength | 637 nm |
| Dimensions | 3 x 4.7mm |
| Lens Colour | Red |
Product Details
Avago HLMP-D101/D105/K101/K105 Series LEDs
The HLMP-D101/D105 and HLMP-K101/K105 series, from Avago Technologies, are high intensity LED lamps. This family of solid-state LED lamps use double heterojunction (DH) AlGaAs/GaAs material technology. Their LED material offers a high light output efficiency over a range of drive currents.
The HLMP-D101/D105 and HLMP-K101/K105 LEDs are deep red in colour with a wavelength of 637 nanometers. They can be DC driven or pulse driven by the user to acheive the required light output.
Suitable applications for the HLMP-D101/D105 and HLMP-K101/K105 LEDs include; bright ambient lighting, moving message panels, portable equipment and general purpose use.
The HLMP-D101/D105 and HLMP-K101/K105 LEDs are deep red in colour with a wavelength of 637 nanometers. They can be DC driven or pulse driven by the user to acheive the required light output.
Suitable applications for the HLMP-D101/D105 and HLMP-K101/K105 LEDs include; bright ambient lighting, moving message panels, portable equipment and general purpose use.
Features of the HLMP-D101/D105, HLMP-K101/K105 LEDs:
– HLMP-D101/D105: T-1 3/4 (5mm) package
– HLMP-K101/K105: T-1 (3mm) package
– AlGaAs red LEDs
– Exceptional brightness
– Wide viewing angle
– Outstanding material efficiency
– Low forward voltage
– CMOS/MOS compatible
– TTL compatible
– Deep red colour
– HLMP-D101/D105: T-1 3/4 (5mm) package
– HLMP-K101/K105: T-1 (3mm) package
– AlGaAs red LEDs
– Exceptional brightness
– Wide viewing angle
– Outstanding material efficiency
– Low forward voltage
– CMOS/MOS compatible
– TTL compatible
– Deep red colour
Visible Light LEDs, Avago Technologies
