Broadcom1.8 V Red LED Rectangular Through Hole, HLMP-S100 | HLMP-S100
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 9 pcs
Mfr. Part No: HLMP-S100
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| LED Colours | Red |
| Package Type | Rectangular |
| Mounting Type | Through Hole |
| Number of LEDs | 1 |
| Forward Voltage | 1.8 V |
| Luminous Intensity | 7.5 mcd |
| Number of Pins | 2 |
| Viewing Angle | 110 ° |
| Lens Shape | Rectangle |
| Dominant Wavelength | 637 nm |
| Dimensions | 2 x 5 x 8mm |
| Lens Colour | Red |
Product Details
Avago HLMP-S100/S20x/S30x/S40x/S50x/S600 Series LEDs
The HLMP-S100, HLMP-S201, HLMP-S301, HLMP-S400, HLMP-S401, HLMP-S501 and HLMP-S600 families, from Avago Technologies, are rectangular LED lamps. They measure 2mm x 5mm in dimension. Encapsulated in an epoxy, their rectangular packages can be stack easily in arrays or for us in discrete front panel indicators. Their contrast and uniform light is helped by a specific epoxy diffusion and tinting process.
The HLMP-S100 uses double heterojunction (DH) absorbing substrate (AS) aluminum gallium arsenide (AlGaAs) LEDs to produce outstanding light output over a wide range of drive currents.
The HLMP-S100 uses double heterojunction (DH) absorbing substrate (AS) aluminum gallium arsenide (AlGaAs) LEDs to produce outstanding light output over a wide range of drive currents.
Features of the HLMP-S100/S20x/S30x/S40x/S50x/S600 LEDs:
– Rectangular light emitting surface
– Ideal for flush mounting on panels
– Variety of bright colours available
– Long life time: solid state reliability
– Uniform light output
– Rectangular light emitting surface
– Ideal for flush mounting on panels
– Variety of bright colours available
– Long life time: solid state reliability
– Uniform light output
Visible Light LEDs, Avago Technologies
