Broadcom1.9 V Orange LED 1606 SMD, HSML-C120 | HSML-C120
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: HSML-C120
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Broadcom |
| LED Colours | Orange |
| Package Type | 1606 |
| Mounting Type | Surface Mount |
| Number of LEDs | 1 |
| Forward Voltage | 1.9 V |
| Luminous Intensity | 90 mcd |
| Number of Pins | 2 |
| Viewing Angle | 155 ° |
| Lens Shape | Dome |
| Dominant Wavelength | 605 nm |
| Lens Colour | Clear |
| Dimensions | 1.6 x 1 x 0.6mm |
Product Details
Avago HSMx-C120 Series LEDs
The HSMx-C120 series, from Avago Technologies, are surface mount (SMT) Chip LEDs. They are in a smaller right angle package with industry standard 1.6 x 0.6 x 1.0 mm.
The HSMx-C120 chip LEDs are designed in an industry standard package for ease of handling and use. Various different LED colours are available in nine compact, single colour packages. Suitable applications for the HSMx-C120 Chip LEDs include; keypad backlighting, push-button backlighting, LCD backlighting, symbol backlighting and front panel indicators.
The HSMx-C120 chip LEDs are designed in an industry standard package for ease of handling and use. Various different LED colours are available in nine compact, single colour packages. Suitable applications for the HSMx-C120 Chip LEDs include; keypad backlighting, push-button backlighting, LCD backlighting, symbol backlighting and front panel indicators.
Features of the HSMx-C120 series:
– Compact package
– Industry standard 0603 footprint
– Viewing angle: 155°
– Compatible with IR solder
– Diffused optics
– Operating temperature range of -30°C to +85°C
– Various colours available
– Compact package
– Industry standard 0603 footprint
– Viewing angle: 155°
– Compatible with IR solder
– Diffused optics
– Operating temperature range of -30°C to +85°C
– Various colours available
Visible Light LEDs, Avago Technologies
