Bulgin Door Micro Switch Lever, SPDT 5 A IP44, 125 °C | E3111DAAAA

Name: Bulgin Door Micro Switch Lever, SPDT 5 A IP44, 125 °C | E3111DAAAA
SKU: 9318-402
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 5 pcs

Mfr. Part No: E3111DAAAA

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 9318-402 Categories: Bulgin, Door Interlock Switches

Description

Specifications

Attribute	Value
Brand	Bulgin
Actuator Type	Lever
Product Type	Door Micro Switch
Contact Configuration	SPDT
Contact Current	5A
Terminal Type	Quick Connect
Housing Material	Polyamide
IP Rating	IP44
Mechanical Life	50000Cycles
Contact AC Voltage	250V
Width	22.73 mm
Length	27.56mm
Series	3100
Standards/Approvals	BS EN 61340-5-1:2007, RoHS, ANSI/ESD S20.20:2014, cRL, UL, CSA
Depth	22.73mm
Maximum Operating Temperature	125°C

Product Details

The Bulgin 3100 series refrigerator door switch is not only ideal for traditional refrigerator and freezer applications but can and have been used in a variety of door applications as well. It uses terminal 1,2,3.

Splash resistant

Choice of actuators
