Bulgin MPI002 Series Illuminated Push Button Switch, Momentary, Panel, 19.2 mm Cutout, SPST, Green LED, IP66, 24 V | MPI002/28/GN/6

Name: Bulgin MPI002 Series Illuminated Push Button Switch, Momentary, Panel, 19.2 mm Cutout, SPST, Green LED, IP66, 24 V | MPI002/28/GN/6
SKU: P9535-927
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 9 pcs

Mfr. Part No: MPI002/28/GN/6

Đánh giá: ⭐⭐⭐⭐⭐

SKU: P9535-927 Categories: Bulgin, Push Button Switches

Description

Specifications

Attribute	Value
Brand	Bulgin
Actuator Colour	Silver
Product Type	Push Button Switch
Switch Operation	Momentary
Illuminated	Yes
Series	MPI002
Panel Cutout Size	19.2 mm
Mount Type	Panel
Contact Configuration	SPST
Terminal Type	Tab
LED Colour	Green
IP Rating	IP66
Actuator Style	Button
Contact DC Voltage	24V
Minimum Operating Temperature	-30°C
Maximum Operating Temperature	70°C
Switch Contact Current	50 mA
Standards/Approvals	RoHS

Product Details

Vandal Resistant Switches IP66

Manufactured from Stainless Steel, Bulgin’s range of vandal resistant security switches are designed with a high resistance to wear and tear.

Available with Red, Green and Blue, dot and ring LED illumination

Fitted with integral supply resistor for 6V, 12V and 24V variants

Flying lead or 2.8 mm solder tag termination options

Internal TVS protection

Fully sealed to IP66

Overall length: 35mm + 300mm (flying leads), 32.7mm (2.8mm tags)

Panel cut out; 19.2 mm

Note

If the illumination voltage is not stated an appropriate resistor must be series connected by the user depending on the voltage for each colour as listed on the datasheet.

Warning

Illumination Voltage:
Suffix
/6 → 6Vdc
/12 → 12Vdc
/24 → 24Vdc
/no suffix → The resistor is not installed. The user must select and connect an appropriate resistor in series.
See the datasheet for more details.
