Burkert 8025 Series, Compact Flow Controller, PNP Output, 50 mm Pipe 36 V | 449694
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: 449694
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Burkert |
| Product Type | Flow Controller |
| Terminal Type | Cable Plug |
| Control Output | PNP |
| Mount Type | Compact |
| Maximum Pipe Diameter | 50mm |
| Minimum Operating Temperature | -15°C |
| Maximum Supply Voltage | 36V |
| Maximum Operating Temperature | 80°C |
| Hazardous Area Certification | No |
| Standards/Approvals | EMC |
| Series | 8025 |
Product Details
SE30 HT/S030 HT Flow Control Pulse Transmitter
Designed for high temperature, continuous flow measurement of neutral, slightly aggressive, solid-free liquids, in hazardous environments.
For liquid flow measurement
Frequency output with pulse signal proportional to the flow rate
Interfaces via S030HT pipework flow adaptor with pressure-tight quarter turn mounting. Stainless steel construction permits high temperature (160°C) and pressure ranges (0-40barg)
Connects to remote display, transmitter, batch controller, PLC or SCADA
Typical applications are in hot process cleaning systems (CIP/SIP), hot water, cooling systems, industrial washing machines and chemical plants
Supply voltage: 12-30Vdc
Output signal Open collector, PNP: supply voltage; NPN: 0.2-30Vdc; max. frequency 250Hz
Accuracy up to ≤ 1% FS within 0.5 – 10 m/s (1.0 to 32.8 fps) – optimal velocity 2 – 3 m/s
Medium temperature: -20°C → 160°C
Fluid pressure range: PN40 (dependent on installation adaptor fitting)
Ingress protection: IP65 with cable plug
Body material: PPS, glass fibre reinforced
