Burkert Angle Seat type Pneumatic Actuated Valve, 16 bar 1/2 in | 178684
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: 178684
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Burkert |
| Product Type | Pneumatic Actuated Valve |
| Inlet Connection Type | Threaded |
| Valve Type | Angle Seat |
| Default Valve Position | NC |
| Inlet Port Size | 1/2 in |
| Outlet Connection Type | Threaded |
| Return Type | Spring |
| Outlet Port Size | 1/2 in |
| Maximum Operating Pressure | 16 bar |
| Valve Material | Stainless Steel |
| Outlet Thread Standard | G |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | No |
Product Details
Burkert Pneumatic Valve
The Burkert pneumatic valve with angle seat ½in G connection has normally closed (NC) configuration and is made of gunmetal for maximum operating pressure of 16bar. It has a 2/2-way configuration with the under-seat flow for liquids. This anti-water hammer valve employs live loaded packing and an N-seal piston actuator, all in an application proven rugged compact envelope.
Features and Benefits
Ambient temperature ranging between –10°C and 60°C
Flow rate is 4.2m³/h
High flow rate because of compact design
Intermediate relief
Media temperature ranging between –10°C and 180°C
Orifice is 15mm
Polyamide actuator casing and PTFE seal material
Self-adjusting spindle packing glands
Wiper seal
Certifications
GL approved
SIL approved
